Short answer: Computer chips, or integrated circuits, are made on wafers of very pure silicon. Each wafer is coated with a light-sensitive photoresist and exposed to ultraviolet light through a mask in a step called photolithography, which prints the circuit pattern.

Etching removes unwanted material, and the steps of deposition, doping, lithography and etching are repeated many times to build up billions of transistors. Finished wafers are tested and cut into individual dies, which are packaged into chips. The footage shows chip fabs and cleanrooms, with the presenter.
