Vertical Parking II

Short answer: Giken's ECO Cycle is a robotic bike park buried in a cylinder under the pavement. Above ground there's only a small entrance booth.

You push your bike onto a slot and press a button, and a rotating elevator stores it in a ring of racks underground. A standard unit holds about 200 bikes. To get your bike back, you tap an IC card, and it returns in about 13–15 seconds on average. The first unit opened in 1998, and they now sit beside busy stations in Tokyo and other Japanese cities.

VideoWrite-up5 sources

In collections:Engineering Oddities

More like this★ Support my pagesCite this file

What should you know about Vertical Parking II?

Quick facts. Each one stands alone and has a stable ID you can cite.

  1. Giken's ECO Cycle stores about 200 bicycles in an underground silo beneath a booth the size of a parked car.

    DD-009-F01 · Write-up · Exhibit A (Culture above ground, function underground)

  2. A bike parked in an ECO Cycle comes back up in about 13–15 seconds on average after the owner taps an IC card.

    DD-009-F02 · Write-up · Exhibit E (Back in seconds)

Video transcript: Vertical Parking II: This Robot Parks 200 Bikes Underground

DID YOU KNOW? Automated underground bicycle storage systems are compact, robotic facilities that store bikes vertically beneath the street to save space in dense urban areas. One of the best known examples is the Ecocycle System by Giken Ltd., widely used in cities like Tokyo. Retrieval takes only seconds, with the system automatically selecting and returning the correct bicycle. NOW YOU KNOW!

Burned-in captions, read frame by frame (see transcript.md) · 19.9s Reel ·

Video coming soonVertical Parking II · Instagram Reel
Vertical Parking II: This Robot Parks 200 Bikes Underground Instagram Reel · · 19.9s

The write-up

This robot parks 200 bikes underground. Japan's ECO Cycle brings yours back up in about 15 seconds.

  1. Exhibit A

    Culture above ground, function underground

    ECO Cycle is Giken's automated bicycle park. A small entrance booth sits on the pavement, and the parking spaces are buried below it.

  2. Exhibit B

    About 200 bikes per unit

    A standard ECO Cycle holds 200 bicycles. The upgraded model introduced at JR Chiba Station in 2009 holds 204, up from 144 in earlier units.

  3. Exhibit C

    A rotating elevator

    Bikes are stored by an elevator that rotates as it moves, filing each bike into the racks around it.

  4. Exhibit D

    Button in, card out

    Users push a button to store a bike and swipe an IC card or tag to get it back. Transit IC cards work too.

  5. Exhibit E

    Back in seconds

    Giken quotes an average retrieval time of 15 seconds, with the fastest at 10 seconds. Other sources give an average of about 13 seconds.

  6. Exhibit F

    Built for crowded stations

    ECO Cycles were designed to clear illegally parked bikes from station pavements. By about 2016, 36 units at 13 sites stored 6,605 bikes, at places such as Roppongi, Shinagawa and Kyoto stations.

  7. Exhibit G

    Earthquake-proof

    The structure is built to withstand an earthquake of Japanese seismic intensity 6-upper.

Questions people ask about Vertical Parking II

Which company makes the ECO Cycle underground bike park?

ECO Cycle is made by Giken Ltd. of Japan.

Source: Write-up · Exhibit A (Culture above ground, function underground) · Automated Parking Facility ECO Cycle (Giken Ltd., English brochure); Anti-seismic Underground Bicycle Park – ECO Cycle (JSME award summary)

About how many bikes does a standard ECO Cycle hold?

The standard spec is 200 bikes; the upgraded model holds 204.

Source: Write-up · Exhibit B (About 200 bikes per unit) · エコサイクルの仕様 / ECO Cycle specifications (Giken Ltd.); Automated Parking Facility ECO Cycle (Giken Ltd., English brochure); Anti-seismic Underground Bicycle Park – ECO Cycle (JSME award summary)

How do users get their bike back?

Swiping an IC card or tag starts retrieval; transit cards work too.

Source: Write-up · Exhibit D (Button in, card out) · Automated Parking Facility ECO Cycle (Giken Ltd., English brochure); エコサイクルの利用方法 / How to use ECO Cycle (Giken Ltd.)

What's the average retrieval time?

Giken quotes an average of 15 s (fastest 10 s).

Source: Write-up · Exhibit E (Back in seconds) · Automated Parking Facility ECO Cycle (Giken Ltd., English brochure); エコサイクルの利用方法 / How to use ECO Cycle (Giken Ltd.); Anti-seismic Underground Bicycle Park – ECO Cycle (JSME award summary); Bicycles getting sucked into the ground?! The 'Hi-Tech' bicycle parking lot (FUN! JAPAN)

What problem were ECO Cycles designed to solve?

They clear crowded station pavements by moving parking underground.

Source: Write-up · Exhibit F (Built for crowded stations) · Anti-seismic Underground Bicycle Park – ECO Cycle (JSME award summary); Bicycles getting sucked into the ground?! The 'Hi-Tech' bicycle parking lot (FUN! JAPAN)
